Name: Lenze E84AYM10S 8400 Drive Memory Module
Availability: InStock

Lenze E84AYM10S 8400 Drive Memory Module

DRIVE CONFIGURATION MEMORY8400 SERIES

Lenze E84AYM10S is a pluggable memory module used to retain and transfer parameter sets in supported 8400 inverter drives. It supports controlled commissioning and service replacement when hardware and firmware are checked together.

MATCH BEFORE ORDERINGConfirm the installed 8400 drive line, firmware level, memory-module hardware version and validated parameter source before copying.

MODULE ROLEParameter storage

COPYING TOOLEZAEDE1001

APPLICATIONSeries commissioning

Brand New Original One Year Warranty

INQUIRE NOW

OFFICIAL COMPATIBILITY DATA

E84AYM10S firmware and copying conditions

Lenze support notices define the hardware-generation and firmware checks needed before a parameter-memory exchange.

DRIVE & SOFTWARE CONTEXT

Product roleDrive parameter memory

Supported inverter lines8400 StateLine, HighLine and TopLine

Supported variants8400 protec StateLine and HighLine

Compatibility checkDrive firmware and module hardware revision

Application scopeAll applications in the Lenze support record

New hardware supportFirmware V20.00 or later

Previous hardware supportMaintained by newer firmware

Hardware identificationReadable with Lenze Tools

Memory module copierEZAEDE1001

Copier purposeFaster series commissioning

COPYING & REVISION CONTROL

Older hardware groupHW <2A

New hardware groupHW ≥2A

Cross-generation copy riskPS02 or PS03 may be logged

Logbook handlingInformation is saved in the logbook

Copying correction baselineFirmware V21.00.00

PS03 removal methodSave the parameter set

Startup behaviorDefault settings load before the actual data

Batch-copy recommendationUse one memory-module version

Compatible-set PS03 changeRemoved from firmware V16.00.00

Compatibility reference8400 software manual

PARAMETER TRANSFER WORKFLOW

How E84AYM10S preserves an 8400 drive setup

A known source configuration, controlled memory copy and matched destination firmware reduce commissioning risk.

01Validate source drive

02Read parameter set

03Copy memory image

04Commission target drive

FUNCTION 01

Retain drive settings

The removable memory stores the configuration needed to reproduce an approved 8400 drive setup.

FUNCTION 02

Support service exchange

Maintenance can move a checked parameter set to a compatible replacement drive without rebuilding every setting manually.

FUNCTION 03

Standardize series machines

The official copier supports repeated preparation of memory modules for machines that share one validated configuration.

FUNCTION 04

Separate data from power hardware

Configuration memory can be handled as a service item while the inverter power section remains a separate compatibility decision.

FUNCTION 05

Control revision differences

Hardware-version and firmware checks prevent unsupported copying paths from being treated as equivalent.

FUNCTION 06

Reduce restart uncertainty

A documented source image and destination review make post-replacement testing more predictable.

COPYING DISCIPLINEUse one known memory-module hardware version per copying batch and record the destination firmware.

BUYER GUIDANCE

Lenze E84AYM10S buyer FAQ

These questions focus on parameter transfer, firmware generations and the evidence needed for a reliable replacement quote.

Why is the hardware version important when ordering Lenze E84AYM10S?

Lenze documents copying differences between memory-module hardware versions below 2A and versions from 2A. Record the installed label before replacement.

Which firmware should be checked for Lenze E84AYM10S new-hardware support?

The official support record states that the newer memory-module hardware is supported from firmware V20.00.

Can Lenze E84AYM10S be duplicated for series commissioning?

Yes. Lenze identifies memory module copier EZAEDE1001 for duplicating prepared module data used in series commissioning.

What changed for Lenze E84AYM10S copying from firmware V21.00.00?

Lenze states that a compatibility issue affecting copied module hardware generations was corrected from firmware V21.00.00.

What must be verified before replacing Lenze E84AYM10S in an operating drive?

Confirm the drive family, firmware, module hardware version and a backed-up parameter set; then test the destination configuration under controlled conditions.

What information produces an accurate Lenze E84AYM10S quotation?

Provide photographs of both labels, the 8400 drive type, firmware version, required quantity and delivery country, and request the relevant Lenze support documentation.
