Name: Allen-Bradley 20-COMM-C PowerFlex ControlNet To DPI Communication Adapter
Availability: InStock

TECHNICAL LEDGER

20-COMM-C Technical Parameter Guide.

Network media, host interface, cyclic data and configuration boundaries for the exact ControlNet adapter.

NETWORK PROTOCOL

ControlNet

NETWORK MEDIUM

Coaxial

HOST INTERFACE

DPI

CHANNEL A CONNECTOR

BNC

NETWORK REVIEW

Treat the drive and ControlNet segment as one project.

Confirm host compatibility, firmware, carrier, node address, channel cabling and controller I/O before exchange.

Channel B connector

Redundant BNC

DPI connector

20-pin male header

Status indicators

Node addressing

Hardware switches / parameter

Cyclic control

Logic Command / Reference

Cyclic feedback

Logic Status / Feedback

Datalink capacity

Up to 4 pairs

Explicit messaging

Supported

Network hierarchy

Master / slave

Fault actions

Communication / idle

Current firmware download

3.001

PowerFlex 750 mounting

Carrier card required

Hardware series

Series A / Series B

Series A firmware

FRN 2.xxx

Series B firmware

FRN 3.xxx

External comms kit

20-XCOMM-DC-BASE

ADAPTER CLASS

Communication

MEDIA

Coaxial ControlNet

HOST PROTOCOL

DPI

LIFECYCLE

Active Mature

COUNTRY OF ORIGIN

Mexico

CONTROL DATA PATH

From ControlNet controller commands to PowerFlex drive feedback.

A functional view of cyclic I/O, parameter messaging and adapter diagnostics.

Cyclic drive control

Controller command and reference data travel through the adapter while drive status and feedback return on the network.

Application Datalinks

Selected host parameters can be added to the scheduled I/O image for application-specific data exchange.

Explicit access

Unscheduled messaging supports parameter and diagnostic access outside the cyclic control path.

HOSTIdentify

FIRMWAREConfirm

NODEAssign

CHANNELSConnect

I/OValidate

MODEL FAQ

Common buyer questions about 20-COMM-C.

Concise answers for a more confident purchasing decision.

QUESTION01

How do the two BNC ports on Allen-Bradley 20-COMM-C support ControlNet media?

Channel A is the primary coaxial connection and Channel B supports redundant media when the network is designed for redundancy; both must follow the installed ControlNet topology.

QUESTION02

What is the difference between scheduled I/O and explicit messaging on Allen-Bradley 20-COMM-C?

Scheduled I/O carries cyclic Logic Command, Reference, Logic Status and Feedback data, while explicit messaging is used for noncyclic parameter and diagnostic access.

QUESTION03

How many Datalinks can Allen-Bradley 20-COMM-C add to the drive data exchange?

The adapter supports up to four Datalink pairs, subject to the compatible DPI host, controller project and selected I/O configuration.

QUESTION04

Which hosts need extra mounting hardware for Allen-Bradley 20-COMM-C?

PowerFlex 750-Series installation requires the appropriate carrier card, while some external DPI applications use the 20-XCOMM-DC-BASE kit; confirm the exact host publication.

QUESTION05

When is 20-750-CNETC a possible alternative to Allen-Bradley 20-COMM-C?

Rockwell recommends 20-750-CNETC where possible for PowerFlex 750-Series drives, but 20-COMM-C is Active Mature and the alternative is not universal across every supported DPI host.
