Bucher Automation JM-204-480-S1 JetMove Servo Amplifier

BUCHER AUTOMATION / JETMOVE 200400 V SERVO AMPLIFIER
SAFE MOTION POWER STAGE

JM-204-480-S1

Bucher Automation JM-204-480-S1 is a 4 A JetMove 204 servo amplifier for three-phase 400 V systems with the S1 safe-stop option.

BEFORE INSTALLATIONConfirm mains class, S1 safety wiring, motor feedback, controller interface, braking hardware and parameter backup.
PRODUCT STATUSManual available
SELECTION CONTROLS1 + FEEDBACK CHECK
Brand New OriginalBest Price ReviewFast Delivery
INQUIRE NOW
  • Worldwide delivery
  • Delivery from stock
  • In stock really means in stock
  • No account required
  • Shipped from the China
Product Specifications
Manufacturer Bucher Automation
Item number JM-204-480-S1
Country of Origin Germany
Lead Time 2-3 DAYS
After-Sales Support For after-sales support, please contact May.
HS Code / Commodity code Please confirm the destination before shipping.
FAQ

Quotes are valid for 30 days from the day the quote is received unless stated otherwise at the time of quotation.

Yes,we offer one year warranty for all new products.

Yes. We worked with FEDEX/DHL/TNT/UPS/ allowing us to provide swift global delivery of parts to any corner of the world.

Normally 3-5 working days,some remote areas 5-7 days more.

Product information
01
FIELD JOURNAL

JM-204-480-S1 Drive and Safety Parameters

Official Bucher Automation power, current, feedback, communication, safety and mechanical details for the exact JetMove configuration.

POWER STAGE, MOTOR & FEEDBACK
CONTINUOUS POWER2 kW
RATED CURRENT4 A
PEAK CURRENT8 A
NOMINAL SWITCHING CONDITION8 kHz
SAFE STOP OPTIONS1 fitted
MOTOR CLASSSynchronous servo motor
ENCODER INTERFACESEnDat 2.2, HIPERFACE, incremental, resolver, SinCos
SYSTEM BUSJX2-Systembus
CONTROLLER LINKJC-310 or Ethernet 10/100 Mbit/s
ANALOG INPUTSOptional
CONTROL, SAFETY & MECHANICAL
ENCODER EMULATOROptional
CONTROL SUPPLY24 VDC
BRAKINGInternal / external braking-resistor arrangement per manual
MOTOR TEMPERATURE MONITORINGSupported through approved motor connection
COMMISSIONING SOFTWAREJetSym / drive tools per system configuration
INSTALLATION ORIENTATIONVertical in control cabinet
COOLINGConvection / cabinet airflow per manual
PROTECTIVE EARTHRequired
DIMENSIONS72 x 310 x 280 mm
WEIGHT4.2 kg including STO
02
FIELD JOURNAL

How JM-204-480-S1 Controls and Safely Disables a Servo Axis

A commissioning route from the three-phase supply and motor feedback to controller commands, safe-stop wiring and tested motion.

USE 01

Drive a synchronized machine axis

Use the digital servo loops with the selected motor encoder for accurate cyclic motion under JetControl supervision.

USE 02

Integrate diverse feedback hardware

Select the installed resolver, sine, incremental or absolute encoder interface specified for the motor configuration.

USE 03

Implement a safe torque interruption

Wire the S1 option into the machine safety circuit and validate the resulting stop category at system level.

USE 04

Coordinate axes over the JX2 bus

Exchange commands and status with the compatible controller using the documented JetMove communication architecture.

USE 05

Manage regenerative energy

Size and connect the braking arrangement for the actual inertia, cycle time and DC-bus energy profile.

USE 06

Restore a legacy motion station

A correctly matched spare can retain an installed axis when configuration files, encoder data and wiring records are available.

03
FIELD JOURNAL

Common buyer questions about JM-204-480-S1

Practical purchasing guidance for clearer, more confident decisions.

01BUYER QUESTION

What does the S1 suffix mean for Bucher Automation JM-204-480-S1?

The S1 configuration includes the safe-stop option. It must be connected and validated as part of the complete machine safety circuit; the drive option alone does not establish a safety function.

02BUYER QUESTION

Which feedback interface should be selected for Bucher Automation JM-204-480-S1?

Use the interface required by the exact motor encoder. The official product data lists EnDat 2.2, HIPERFACE, incremental, resolver and SinCos choices, but the installed hardware and parameters must agree.

03BUYER QUESTION

How is regenerative energy handled around Bucher Automation JM-204-480-S1?

The braking-resistor and DC-bus arrangement must be sized from motor inertia, deceleration rate and duty cycle. Follow the official manual and do not copy values from another axis.

04BUYER QUESTION

Which controller architecture can operate Bucher Automation JM-204-480-S1?

The official product page lists JX2-Systembus and a JC-310 or Ethernet 10/100 Mbit/s controller path. Confirm the machine controller, project and installed communication hardware.

05BUYER QUESTION

What must be preserved before exchanging Bucher Automation JM-204-480-S1?

Save the parameter set, motor and encoder data, controller project, safety wiring record, firmware information and connector photos before disconnecting the existing amplifier.

06BUYER QUESTION

How should the JetMove manual, availability and nameplate data be packaged for a JM-204-480-S1 quotation?

Use Bucher Automation's official JetMove 204 manual and confirm supply for the complete S1 configuration. Provide the full number, serial and revision data, motor and feedback type, safety-option requirement, quantity and destination.
