Description:Bently Nevada 330400-02-05 is an Accelerometer for vibration monitoring.
Product condition: New
Packing condition:Factory Packing
100% insured shipping: A guarantee for your purchases
PLC Autocontroller DELIVER PARTS TO WORLD.
| Manufacturer | Bently nevada |
| Item number | 330400-02-05 |
| Country of Origin | United States |
| Lead Time | In stock |
| After-Sales Support | 12-months |
| HS Code / Commodity code | 8537101190 |
Quotes are valid for 30 days from the day the quote is received unless stated otherwise at the time of quotation.
Yes,we offer one year warranty for all new products.
Yes. We worked with FEDEX/DHL/TNT/UPS/ allowing us to provide swift global delivery of parts to any corner of the world.
Normally 3-5 working days,some remote areas 5-7 days more.
1. One-line summary
The 330400-02-05 is Bently Nevada’s most quoted 100 mV/g general-purpose accelerometer: hermetic, titanium, ¼-28 integral stud, certified for Zone-2, ATEX, IECEx, ABS & DNV—ready for gas turbines, cooling-tower fans or offshore pumps.
2. Instant Spec Table
|
Parameter |
Value |
Notes |
|
Sensitivity |
100 mV/g ±10 % |
10–5 000 Hz ±3 dB |
|
Range |
0–80 g peak |
overload 1 000 g shock |
|
Temperature |
–55 °C … +125 °C |
no thermal zero shift |
|
Supply |
15 – 30 Vdc @ 2 mA |
constant-current 2–10 mA |
|
Housing |
Hermetic titanium |
0.7″ hex, 1.4″ height |
|
Stud |
¼-28 UNF integral |
no adapter needed |
|
Seal |
IP 68 / NEMA 4X |
100 h salt-spray per ASTM B117 |
|
Approvals |
ATEX II 3G Ex ic IIC T4 Gc, IECEx, CE, ABS, DNV |
multi-card ready |
3. Approval Matrix (why it travels everywhere)
|
Cert Body |
Code |
Zone / Class |
|
ATEX |
Sira 21ATEX2187X |
Zone 2, Ex ic IIC T4 Gc |
|
IECEx |
IECEx SIR 21.0040X |
Zone 2, Ex ic IIC T4 Gc |
|
ABS |
21-2156721-PDA |
Marine hull & machinery |
|
DNV |
TAA00001R9 |
Offshore vibration monitoring |
4. Mounting Cheat-Sheet
ü Spot-face ≤ 32 µin Ra
ü 5–7 N·m (45–60 in-lb) on integral stud – no grease
ü Orient connector toward junction box → reduces drip-loop stress
ü Lock-wire optional for > 4 000 RPM fans
5. One-Minute Order Path
Sales Manager May
ab@mooreplc.com | +86-18106909650 (WhatsApp) | WeChat: dcsfcs
Send: “330400-02-05 + cable length + destination” – price in 15 min, 1-year warranty.
6. Take-away
Need a single, globally-accepted accelerometer that bolts on with one hand and forgets the world for ten years? 330400-02-05 is the titanium workhorse—keep a few in the store-room and stop hunting approvals.
