Description:330103-00-10-10-12-05 — 8 mm XL proximity probe with M10×1 thread and FluidLoc cable for accurate vibration and displacement measurement in Bently Nevada monitoring systems.
Product condition: New
Packing condition:Factory Packing
100% insured shipping: A guarantee for your purchases
PLC Autocontroller DELIVER PARTS TO WORLD.
| Manufacturer | Bently nevada |
| Item number | 330103-00-10-10-12-05 |
| Country of Origin | United States |
| Lead Time | In stock |
| After-Sales Support | 12-months |
| HS Code / Commodity code | 8537101190 |
Quotes are valid for 30 days from the day the quote is received unless stated otherwise at the time of quotation.
Yes,we offer one year warranty for all new products.
Yes. We worked with FEDEX/DHL/TNT/UPS/ allowing us to provide swift global delivery of parts to any corner of the world.
Normally 3-5 working days,some remote areas 5-7 days more.
PLC Autocontroller | Spare Parts Speed 20 Years
Sales Manager May | Email: ab@mooreplc.com | Tel: +86-18106909650 (WhatsApp) | WeChat: dcsfcs
Ø Product Overview
330103-00-10-10-12-05 is the standard probe assembly of the Bently Nevada 3300 XL 8mm eddy current probe system in the United States, which is used for online monitoring of shaft vibration, shaft displacement, rotational speed and key phase of rotating equipment such as steam turbines, compressors, pumps and fans. This probe features a stainless steel housing and PPS wear-resistant end, and is equipped with FluidLoc™ cables and ClickLoc™ micro connectors. It can operate stably for a long time in harsh environments ranging from -52 °C to +218 °C. Complies with API 670 and ATEX/IECEx Zone 0/1 explosion-proof requirements.
Spec-Snapshot Table
|
Item |
Specification |
|
Model: |
330103-00-10-10-12-05 |
|
Probe diameter: |
8mm |
|
Thread: |
M10 × 1 |
|
With armor: |
without armor |
|
Measurement stroke: |
0mm - 100mm |
|
Cable length: |
1.0 meter (3.3 feet) |
|
Interface type: |
Miniature coaxial ClickLoc connector |
|
cable type: |
FluidLoc cable |
|
Certifications: |
CSA, ATEX, IECEx Approvals |
Advantages
API 670 is fully compatible - it can be interchanged with the old 3300/7200 series without the need for recalibration.
Zone 0 Explosion-proof - Certified by ATEX/IECEx/CSA multiple times, suitable for high-risk places such as oil and gas platforms and oil refineries.
ClickLoc™ Self-locking connector - 360° rotation locking can be achieved with one hand, anti-vibration and anti-disengagement, reducing installation time by 50%.
FluidLoc™ Oil-blocking Cable - Special sheath prevents lubricating oil from migrating along the cable, extending the probe's lifespan.
The temperature drift is extremely low - the sensitivity variation is less than 2% within the range of -52 °C to +218 °C, ensuring long-term measurement accuracy.
High EMI/RFI resistance - CE certified, can be installed in a fiberglass chassis without the need for a metal shielding conduit
