Name: Allen-Bradley 22B-A8P0N104 PowerFlex 40 1.5 kW AC Drive
Availability: InStock

Allen-Bradley 22B-A8P0N104 PowerFlex 40 1.5 kW AC Drive

ALLEN-BRADLEY · POWERFLEX DISCONTINUED

POWERFLEX 40 / AC DRIVE

22B-A8P0N104

Allen-Bradley 22B-A8P0N104 is a discontinued PowerFlex 40 frame-B drive rated 1.5 kW, 2 HP and 8 A at 240V AC.

POWERFLEX 40 2 HP / 240V AC

NETWORK ROLE PowerFlex AC Drive

IN NODE OUT

STATUS Lifecycle status: Discontinued / Obsolete by OEM

Brand New Original One Year Warranty Fast Delivery

REQUEST A QUOTE Inquire Now Send the module label, existing network layout, quantity and destination for a focused review. ab@mooreplc.com ↗

VERIFIED PRODUCT DATA

Product specifications

Core electrical, network, environmental and mechanical data.

Drive familyPowerFlex 40

Input voltage200…240V AC, single phase

Input frequency50…60 Hz

Output current8.0 A

Power rating1.5 kW (2 HP)

Frame sizeB

EnclosureIP20, NEMA/UL Type Open

MountingPanel mount

User interfaceIntegral keypad and LED display

EMC filterNo CE-compliant filter

Communication interfaceRS485

Brake IGBTIncluded

Power factor0.98

Dimensions (W × H × D)100 × 180 × 136 mm (3.94 × 7.09 × 5.35 in.)

Ship weight2.2 kg (4.9 lb)

Discontinued dateJune 30, 2025

Engineering replacement25B-A8P0N104

Warranty duration1 year

FUNCTION & APPLICATION

Network integration

How the adapter is used, installed and checked in its intended control architecture.

SYSTEM PATH

PLCADAPTERI/O

Use the product-specific wiring and controller project as the final integration reference.

MOTOR CONTROL

PowerFlex 40 AC drive

The drive controls a 1.5 kW motor from a 200…240V AC single-phase input with an 8 A output rating.

PANEL INTEGRATION

Frame-B open enclosure

Plan panel mounting, ventilation, terminal wiring and the IP20/NEMA open enclosure conditions.

REPLACEMENT REVIEW

Engineering replacement path

Rockwell identifies 25B-A8P0N104 as the engineering replacement; compare the application and parameters before migration.

PURCHASING QUESTIONS

FAQ

Clear answers for selection, installation, replacement review and quotation.

What motor rating is specified for Allen-Bradley 22B-A8P0N104?

Rockwell identifies the PowerFlex 40 drive as 1.5 kW (2 HP) with an 8.0 A output current rating.

What input supply does Allen-Bradley 22B-A8P0N104 require?

The official product description specifies 200…240V AC, single phase, at 50…60 Hz for this frame-B drive.

What interface and operator controls are built into Allen-Bradley 22B-A8P0N104?

Rockwell lists RS485 communication, an integral keypad and LED display, and an included brake IGBT.

Is Allen-Bradley 22B-A8P0N104 available as a current OEM product?

No. Rockwell lists it as Discontinued with a June 30, 2025 discontinuation date and identifies 25B-A8P0N104 as the engineering replacement.

Can 25B-A8P0N104 replace Allen-Bradley 22B-A8P0N104 without parameter review?

It is an engineering replacement, not an automatic drop-in guarantee. Confirm motor data, enclosure, wiring, control method, communications and the existing parameter set.

Which documents should be supplied when quoting Allen-Bradley 22B-A8P0N104?

Rockwell lists 22B-UM001 user manual and 22B-SR001 specification sheet; provide the nameplate, motor details, quantity and destination for a replacement review.
