Name: B&R X20PS9602 Compact-S PLC Power Supply Module
Availability: InStock

B&R X20PS9602 Compact-S PLC Power Supply Module

PRODUCT ENQUIRY

Compact-S CPU and X2X power distribution

Inquire Nowab@mooreplc.com →

B&RCOMPACT-S POWER

X20PS9602

B&R X20PS9602 is a 24 VDC Compact-S power supply module with integrated serial and CAN interfaces for X20 automation systems.

● One Year Warranty● Fast Delivery● Worldwide Shipping

OFFICIAL ENGINEERING DATA

Supply output, interface and installation specifications

Official limits show where the non-isolated Compact-S supply can be used safely.

B&R ID code0xEB04Supply functionCompact-S PLC, X2X Link and internal I/O

Input voltage24 VDC -15% / +20%Maximum input current0.7 A

Input protectionIntegrated non-replaceable fuseReverse-polarity protectionProvided on CPU / X2X input

Nominal output power7 WParallel operationNot permitted

Redundant operationNot supportedOverload behaviorShort-circuit proof with temporary overload

I/O output voltage24 VDCI/O contact load10 A

Internal I/O consumption0.6 WX2X supply consumption1.64 W

Serial interfaceRS232 or RS485 via X20TB12Maximum serial rate115.2 kbit/s

CAN interface1 channel via X20TB12Maximum CAN rate1 Mbit/s

Electrical isolationPLC and X2X supply not galvanically isolatedDegree of protectionIP20

Horizontal operation-25 to 60°CVertical operation-25 to 50°C

Required baseX20BB5x, X20BB6x or X20BB7xModule pitch12.5 +0.2 mm

FROM INPUT TO CONTROL

How X20PS9602 powers a Compact-S station

One module feeds the controller, X2X electronics and I/O while exposing base-dependent serial and CAN paths.

Accept

The protected 24 VDC input supplies the Compact-S CPU and X2X Link power path.

Distribute

The module provides the documented output power for controller and internal I/O operation.

Connect

The selected Compact-S base exposes RS232, RS485 and CAN through the X20TB12 terminal block.

Protect

Status LEDs and software report operating state, interface activity and overload conditions.

ENGINEERING FIT

FIT 01

Small Compact-S systems

Use the cost-effective supply where one Compact-S controller and local X20 I/O are sufficient.

FIT 02

Potential groups

Create documented I/O potential groups without assuming CPU/X2X galvanic isolation.

FIT 03

Base-specific communication

Choose the X20BB base that exposes the required serial or CAN interface.

BUYER QUESTIONS

FAQ for B&R X20PS9602

Model-specific answers support engineering and purchasing decisions.

What isolation limitation is important with B&R X20PS9602?

B&R states that the PLC and X2X Link supply is not galvanically isolated, so system grounding and interface planning must reflect a common supply reference.

Can two B&R X20PS9602 modules be paralleled for more power or redundancy?

No. B&R explicitly states that parallel connection and redundant operation are not supported.

Which Compact-S bases are used with B&R X20PS9602?

B&R instructs users to order a compatible X20BB5x, X20BB6x or X20BB7x base and an X20TB12 terminal block separately.

Why is B&R X20PS9602 intended for small X20 systems?

Its 7 W CPU/X2X output is designed as a cost-effective supply, and B&R does not permit network expansion or redundancy through additional parallel supply modules.

When would B&R X20PS9600 require evaluation instead of B&R X20PS9602?

Evaluate X20PS9600 when the application needs the isolation behavior absent from X20PS9602; confirm the Compact-S CPU, base and complete station power budget.

Which station data should accompany a B&R X20PS9602 manual and quote request?

Send the Compact-S CPU and base numbers, X20 slice count, current load, required interfaces, terminal block, quantity and destination.
