Name: B&R X20DO4322 digital output module
Availability: InStock

B&R X20DO4322 digital output module

X20 system digital outputs

X20 DIGITAL OUTPUT

X20DO4322

24 VDC digital output module for distributed X20 I/O stations

16 OUTPUTS24 VDC0.5 A/CH

Inquire Now

PRODUCT ENQUIRY

Switch field devices with confidence.

Share the drive rating, motor, feedback and cabinet requirements for a precise quotation.

ab@mooreplc.com

Brand New Original

One Year Warranty

Worldwide Shipping

Product information

OFFICIAL TECHNICAL DATA

Official technical data for X20DO4322

Configuration-focused information for selection, installation and replacement review.

Output channels4 digital outputsOutput voltage24 VDC

Output typeFET current-sourcingNominal output current0.5 A per channel

Total nominal current2 AOutput connection3-wire connections

Switching delay 0 to 1<300 µsSwitching delay 1 to 0<300 µs

Resistive-load frequencyMax. 500 HzSwitching voltage24 VDC -15% / +20%

Output protectionThermal shutdown for overcurrent or short circuitFreewheeling diodeInternal

Actuator power supply0.5 A totalOff-state leakage current5 µA

RDS(on)210 mΩPeak short-circuit current<12 A

Insulation voltage500 Veff between channel and busModule width12.5 mm pitch

Operating temperature-25 to 60 °CProtection ratingIP20

MOTION WORKFLOW

How X20DO4322 fits the automation system

The 16-channel digital output module switches 24 VDC field devices from a compact B&R X20 remote I/O station.

Bus

Receives process data through the X20 backplane.

Switch

Drives 24 VDC actuators, valves and solenoids.

Diagnose

Reports module and channel status to the controller.

Expand

Adds compact output density to an X20 station.

BUYER DECISION GUIDE

FAQ for B&R X20DO4322

Clear answers for integration, replacement and sourcing.

Q01

How many outputs does B&R X20DO4322 provide?

B&R X20DO4322 provides 16 digital outputs with 24 VDC output voltage and 0.5 A nominal current per channel.

Q02

How is B&R X20DO4322 connected inside an X20 station?

The module exchanges process data through the B&R X20 backplane and uses the station bus for controller communication.

Q03

Which field devices can B&R X20DO4322 switch?

The sourcing transistor outputs are intended for 24 VDC actuators such as valves, relays and solenoids within the rated load limits.

Q04

What protection and status information is available from B&R X20DO4322?

B&R X20DO4322 has group-wise potential isolation, IP20 protection, channel diagnostics and LED channel indication.

Q05

What must match before replacing B&R X20DO4322?

Verify the X20 family, output count, sourcing logic, current requirement, wiring and controller configuration before approving a substitute.

Q06

Which details help quote B&R X20DO4322 accurately?

Provide the complete code, required output quantity, connected load type, X20 station layout, quantity and delivery destination.
