Name: B&R X20BB22 X20 Compact CPU Base Bus Module
Availability: InStock

OFFICIAL TECHNICAL DATA

X20BB22 electrical and operating profile

Exact B&R module characteristics arranged for fast engineering review.

BASE & ELECTRICAL

ENVIRONMENT & APPROVALS

Product categoryX20 Compact CPU base bus module

Vertical operating temperature-25 to 50°C

System roleBackplane for Compact CPU and Compact CPU power supply

Storage and transport temperature-40 to 85°C

Integrated interface1x RS232 connection

Relative humidity5 to 95%, non-condensing

Bus power consumption0.32 W

Module pitch37.5 +0.2 mm

I/O nominal voltage24 VDC

Included componentsLeft and right X20 end cover plates

Permissible contact load10 A

CE and UKCABoth conformity marks listed

Electrical isolationBus not isolated from RS232

ATEXZone 2, II 3G Ex nA nC IIA T5 Gc

Mounting orientationsHorizontal or vertical

ULcULus E115267 industrial control equipment

Installation altitude, 0 to 2000 mNo limitation

HazLoccCSAus 244665, Class I Division 2, Groups ABCD, T5

Above 2000 mReduce ambient temperature by 0.5°C per 100 m

DNVTemperature B, humidity B, vibration B, EMC B

Degree of protectionIP20 per EN 60529

Bureau VeritasEC33B; bridge and open-deck EMC

Horizontal operating temperature-25 to 60°C

Additional marine approvalsCCS, LR ENV1, KR, ABS and KC

USE 01

Seat the Compact CPU

The base provides the documented mounting and backplane position for every B&R X20 Compact CPU.

USE 02

Receive the CPU power module

The adjacent Compact CPU power supply module is installed on the same base assembly and ordered separately.

USE 03

Expose an RS232 channel

The integrated serial connection supports machine-level service or peripheral communication defined by the controller project.

USE 04

Carry the I/O supply path

The base routes the nominal 24 VDC I/O supply with the permissible contact load stated by B&R.

USE 05

Complete the station edges

Left and right X20 end cover plates are supplied with the module for a finished Compact CPU assembly.

USE 06

Support cabinet integration

Horizontal and vertical mounting options allow the base to fit documented X20 cabinet arrangements within the temperature limits.

PURCHASING QUESTIONS

B&R X20BB22 buyer FAQ

Clear purchasing answers for system matching, replacement and documentation decisions.

Which controller assemblies can use B&R X20BB22?

B&R identifies X20BB22 as the base for all X20 Compact CPUs. The exact CPU and its separately ordered Compact CPU power supply module must still be matched before installation.

What wiring issue matters most when integrating B&R X20BB22?

The X20 bus and RS232 interface are not electrically isolated, so cabinet grounding, cable routing and the serial-device reference potential must be reviewed together.

When should an engineer choose B&R X20BB22 instead of X20BB27?

Choose X20BB22 when the Compact CPU assembly needs the documented RS232 base only. X20BB27 is a different official version that adds CAN and an integrated CAN terminating resistor, so it is not an automatic drop-in substitution.

Is B&R X20BB22 discontinued, and can it still be quoted?

B&R currently maintains an official product page, data sheet and hardware-upgrade downloads for X20BB22 without a published discontinuation notice. Stock, condition and revision are confirmed during quotation.

What must be checked before replacing a B&R X20BB22 base?

Verify the installed Compact CPU, CPU power supply module, RS232 wiring, end-cover arrangement, hardware revision, Automation Studio project and environmental approval requirements before replacement.

Which documents and order details help with a B&R X20BB22 inquiry?

Request the official X20BB22 data sheet and X20 System User's Manual, then provide the base label, Compact CPU and power-module numbers, hardware revision, quantity, condition and delivery destination.
