B&R 5MP7150.101E-000 Mobile Panel 7100 10.1-Inch Operator Unit

B&R / MOBILE PANEL 7100SAFETY OPERATOR UNIT
HANDHELD MACHINE INTERFACE

5MP7150.101E-000

B&R 5MP7150.101E-000 is a 10.1-inch Mobile Panel 7100 with an ARM controller, resistive touch, mapp View and VNC operation plus integrated safety-oriented operator controls.

BEFORE INSTALLATIONSelect the B&R connection box, panel cable and safety-circuit architecture as one verified mobile-operator assembly.
SELECTION CHECKVERIFY COMPLETE CONFIGURATION
Brand New OriginalFast DeliveryWorldwide Shipping
INQUIRE NOW
  • Worldwide delivery
  • Delivery from stock
  • In stock really means in stock
  • No account required
  • Shipped from the China
Product Specifications
Manufacturer B&R
Item number 5MP7150.101E-000
Country of Origin Austria
Lead Time 2-3 DAYS
After-Sales Support One Year Warranty
HS Code / Commodity code 853710
FAQ

Quotes are valid for 30 days from the day the quote is received unless stated otherwise at the time of quotation.

Yes,we offer one year warranty for all new products.

Yes. We worked with FEDEX/DHL/TNT/UPS/ allowing us to provide swift global delivery of parts to any corner of the world.

Normally 3-5 working days,some remote areas 5-7 days more.

Product information
01
CONTROL DOSSIER

5MP7150.101E-000 Display, Control and Environmental Parameters

Official B&R technical data for the exact 5MP7150.101E-000 configuration.

ASSEMBLY REVIEWTreat panel and accessories as one system

Verify the exact Mobile Panel label before selecting the cable and connection box.

CONNECTION PACKAGEFour checks complete the mobile station

Compatible 5CAMPB panel cable
Matching 4MPCBX connection box
Validated stop and enable wiring
mapp View or VNC project

COMPUTE & OPERATOR INTERFACE
RESOLUTION1280 x 800 pixels
COLOR DEPTH16.7 million colors
BRIGHTNESS400 cd/m²
CONTRAST800:1
BACKLIGHT HALF-BRIGHTNESS100,000 h
TOUCH TECHNOLOGYAnalog resistive
ETHERNET1x shielded RJ45, 10/100 Mbit/s
USB1x USB 2.0 Type A, max. 500 mA
SYSTEM KEYS22 numeric keys and cursor block
STATUS INDICATORS5 LEDs
STOP BUTTON2 normally closed contacts
SAFETY & INSTALLATION
ENABLE SWITCH3-position, right side
KEY SWITCHIncluded
OPERATING SYSTEMmapp View and VNC client, ARM, English
NOMINAL SUPPLY24 VDC ±25%, SELV
POWER CONSUMPTION12 W typical; 15 W max. with USB
POWER INTERRUPTION≤10 ms
DEGREE OF PROTECTIONIP65
OPERATING TEMPERATURE0 to 45°C
DROP HEIGHT1 m to industrial floor
DIMENSIONS353 x 274 x 109.5 mm
APPROXIMATE WEIGHT2.0 kg
02
CONTROL DOSSIER

5MP7150.101E-000 Supports Mobile Machine Operation

A selection-focused view of function, integration boundaries and practical application roles.

USE 01

Commission beside the machine

Carry the panel to the work area while retaining HMI visibility and local operator controls.

USE 02

Operate safeguarded motion

Use the enable device and stop contacts inside a validated machine safety concept.

USE 03

Display mapp View content

Run B&R web-based visualization sized for the WXGA touch surface.

USE 04

Access a remote HMI session

Use the preinstalled VNC client to reach a compatible visualization host over Ethernet.

USE 05

Enter values with physical keys

Combine the numeric keypad and cursor block with the resistive touch interface.

USE 06

Move between service points

Use the mobile enclosure and matching cable system where operators must work from multiple positions.

03
CONTROL DOSSIER

Common buyer questions about 5MP7150.101E-000

Practical purchasing guidance for clearer, more confident decisions.

BUYER CHECKLISTSend the installed configuration

Complete label and revision
Base and power module
Required interfaces
Automation Studio version

01BUYER QUESTION

Which connection hardware is required for B&R 5MP7150.101E-000?

Select a compatible Mobile Panel 7100 connection box, the correct 5CAMPB panel cable and the intended wall-mount storage accessory. The exact combination depends on safety wiring and connector strategy.

02BUYER QUESTION

How should the stop and enable devices on B&R 5MP7150.101E-000 be integrated?

Treat the two normally closed stop contacts and three-position enable switch as inputs to a separately validated safety circuit. The panel itself does not replace the required risk assessment and safety controller design.

03BUYER QUESTION

Can B&R 5MP7150.101E-000 run both mapp View and VNC applications?

Yes. B&R lists an ARM operating environment with mapp View and a VNC client preinstalled. Confirm the visualization version, network settings and target resolution before deployment.

04BUYER QUESTION

What handling limits matter when B&R 5MP7150.101E-000 is used on the shop floor?

The official data specifies IP65 protection, a 1 m industrial-floor drop rating, 0 to 45°C operation and non-condensing humidity. Cable strain relief and connector protection remain installation responsibilities.

05BUYER QUESTION

Can B&R 5MP7150.101E-000 replace another Mobile Panel without changes?

Not automatically. Compare display resolution, key layout, processor platform, cable type, connection box, safety-contact wiring and visualization software before replacing a different Mobile Panel variant.

06BUYER QUESTION

What should be provided to quote B&R 5MP7150.101E-000 with the correct accessories?

Send the complete panel label, existing cable and connection-box numbers, visualization platform, safety-function requirements, cable length, quantity, condition requirement and destination.
