B&R 4PP452.0571-B5 Power Panel PP452 5.7-Inch Embedded Operator Panel

ALLEN-BRADLEY / POWERFLEXINQUIRY DESK LEGACY HIM20-HIM-A3Full numeric LCD interface for PowerFlex 7-Class drives LIFECYCLEDiscontinued in 2023REPLACEMENT: 20-HIM-A6 Allen-Bradley 20-HIM-A3 PowerFlex 7-Class Full Numeric LCD Human Interface Module Allen-Bradley 20-HIM-A3 provides LCD monitoring, numeric parameter entry and local control for compatible PowerFlex 7-Class DPI drives. DISPLAYLCD + numeric keypad MOUNTINGDrive / handheld Selection note: Confirm the host drive, firmware, mounting method and required interface cable before ordering.  Brand New Original One Year Warranty Fast Delivery Request a 20-HIM-A3 Quote

POWER PANEL 400 · PP452OFFICIAL PAGE 4PP452.0571-B5 B&R 4PP452.0571-B5 is a 5.7-inch Power Panel with hardware keys, embedded control and multiple interfaces. DISPLAY 5.7 in QVGA PROCESSOR Geode LX800 MEMORY 128 MB SDRAM SELECTION ENVELOPE Match the panel cutout, supply, software project and optional aPCI interfaces before replacement. 10 / 100ETHERNET IP65FRONT 24 V DCSUPPLY 20 + 20HARDWARE KEYS ONE YEAR WARRANTY FAST DELIVERY WORLDWIDE SHIPPING INQUIRE NOW

B&R / PANELWARE PW35INQUIRY DESK X2X OPERATOR PANEL4PW035.E300-02160 x 80 monochrome HMI with 26 keys and IP65 front protection LIFECYCLENo phase-out statedTERMINAL: 0TB1108.8110 B&R 4PW035.E300-02 PANELWARE Compact HMI Terminal with X2X Interface B&R 4PW035.E300-02 is a compact HMI with a 160 x 80 monochrome LCD, 26 keys, X2X and 24 V DC input. DISPLAY160 x 80 pixels OPERATOR KEYS26, including 10 LED keys Selection note: Order terminal block 0TB1108.8110 separately and verify X2X station distance, panel cutout and application project.  Brand New Original One Year Warranty 24/7 Service Request a 4PW035.E300-02 Quote

GP77R SERIES · GRAPHIC PANEL 9.1-inch amber electroluminescent operator interface GP477R-EG41-24VP is a Pro-face GP-477R graphic control panel with a 640 × 400 amber electroluminescent display and 24 V DC power input. 640 × 400 display resolution Display size9.1 inch Supply voltage20.4–27.6 V DC Application memory2 MB Flash MOQ 1Minimum order quantity 20 yearsAutomation industry experience Within 24 hoursFast response from PLC Autocontroller Request a quotation using the complete model number, quantity, destination and required date.

B&R / POWER PANEL 400 EMBEDDEDINQUIRY DESK POWER PANEL PP4514PP451.0571-755.7-inch QVGA controller panel with operator keys LIFECYCLENo phase-out stated24 VDC TERMINAL: SEPARATE B&R 4PP451.0571-75 Power Panel PP451 5.7-Inch QVGA Embedded Controller B&R 4PP451.0571-75 combines a 5.7-inch QVGA display, controller, operator keys and industrial interfaces. DISPLAY5.7 in QVGA TFT CONTROLLERGeode LX800 / 500 MHz Selection note: Confirm the cutout, 24 V DC terminal, CompactFlash image and aPCI option.  Top Quality One Year Warranty Worldwide Shipping Request a 4PP451.0571-75 Quote

6AV7241-1BA00-0DA0 is the SIMATIC IPC477E embedded industrial panel PC order variant with a 15.6-inch touch display. The exact processor, storage and operating-system configuration must be confirmed from its Siemens order data and device nameplate. Platform SIMATIC IPC477E Display 15.6-inch touch Product type Embedded Panel PC Configuration Order-specific Verification Nameplate required Engineering Image backup required Send the installed system, firmware, wiring and application requirements for an exact compatibility check.

B&R / POWER PANEL 45 INTERFACESSERIAL + CAN MODULE MULTI-PROTOCOL INTERFACE 4PP045.IF23-1 B&R 4PP045.IF23-1 combines RS232, isolated RS422/RS485 and isolated CAN interfaces for Power Panel 45 machine communication. BEFORE INSTALLATIONConfirm the Power Panel 45 host, selected serial electrical standard, CAN topology and separately ordered 0TB704 terminal block. PRODUCT STATUSOfficial record available SELECTION CONTROLPANEL + TB CHECK APPLICATION SNAPSHOTThree field interfaces for serial devices and CAN networks on Power Panel 45 Official selection note: PANEL + TERMINAL CHECK SERIAL PORTSRS232 + RS4xx FIELD NETWORKIsolated CAN Module rolePP45 interface Serial interface IF1RS232 Brand New OriginalFast DeliveryWorldwide Shipping INQUIRE NOW

B&R / POWER PANEL PP4205.7-INCH HMI CONTROLLER PANEL CONTROL PLATFORM 4PP420.0571-75 B&R 4PP420.0571-75 combines a 5.7-inch QVGA resistive touchscreen, Geode LX800 CPU and industrial Ethernet, serial and USB ports. BEFORE INSTALLATIONConfirm panel cutout, supply terminal, Automation Runtime project, CompactFlash, battery and optional aPCI hardware. PRODUCT STATUSOfficial record available SELECTION CONTROLCUTOUT + PROJECT APPLICATION SNAPSHOTQVGA resistive-touch operator panel with embedded Automation Runtime controller Official selection note: VERIFY CUTOUT + PROJECT DISPLAY5.7 in · 320 × 240 CPU CLOCK500 MHz B&R ID code0xA159 ProcessorGeode LX800 Brand New OriginalOne Year WarrantyWorldwide Shipping INQUIRE NOW
