Siemens 6SL3255-0AA00-4CA1 SINAMICS G120 Basic Operator Panel BOP-2

Siemens 6SL3255-0AA00-4CA1 SINAMICS G120 Basic Operator Panel BOP-2

Name: Siemens 6SL3255-0AA00-4CA1 SINAMICS G120 Basic Operator Panel BOP-2
Availability: InStock

6SL3255-0AA00-4CA1 is the Siemens SINAMICS G120 Basic Operator Panel BOP-2 for commissioning, monitoring and individual parameter entry.

Display
Monochrome LCD

Protection
IP55 / UL Type 12

Operation
0 to 50 °C

Lifecycle
PM300 Active Product

Send the converter type, Control Unit, firmware and mounting method for a compatibility check.

Inquire Now

Worldwide delivery
Delivery from stock
In stock really means in stock
No account required
Shipped from the China

Product Specifications

Manufacturer	Siemens
Item number	6SL3255-0AA00-4CA1
Country of Origin	United Kingdom
Lead Time	Subject to availability; confirm at order time
After-Sales Support	Technical documentation and model verification support
HS Code / Commodity code	85371091

FAQ

How long is my quote valid for?

Quotes are valid for 30 days from the day the quote is received unless stated otherwise at the time of quotation.

Is there any warranty?

Yes,we offer one year warranty for all new products.

Do you offer global delivery?

Yes. We worked with FEDEX/DHL/TNT/UPS/ allowing us to provide swift global delivery of parts to any corner of the world.

How many days will it take for my part to arrive?

Normally 3-5 working days,some remote areas 5-7 days more.

Product information

SINAMICS G120 · LOCAL DRIVE INTERFACE

6SL3255-0AA00-4CA1

Basic Operator Panel BOP-2

PM300 ACTIVE PRODUCTIP55 / UL TYPE 12

CONTACT & QUOTE

Talk to our automation team

E-mail: ab@mooreplc.com WhatsApp: +86-18106909650

Send the exact MLFB, quantity and destination for a fast model and availability check.

PRODUCT POSITIONING

A compact interface for commissioning and local drive checks

6SL3255-0AA00-4CA1 is the Siemens SINAMICS G120 BOP-2. Siemens specifies it for commissioning drives, monitoring drives during operation and entering individual parameter settings.

The menu-guided workflow and two-line monochrome display support practical work at the converter. Compatibility should always be checked against the exact SINAMICS Control Unit and firmware.

OPERATING FLOW

COMMISSION

Use the menu-guided dialog for basic drive settings.

MONITOR

View drive operating information locally.

PARAMETERIZE

Enter and review individual parameters.

PRODUCT SPECIFICATIONS

Official Siemens data

Display
LCD, monochrome

Protection
IP55 / UL Type 12

Dimensions
70 × 106.85 × 19.6 mm

Net weight
0.140 kg

Operation
0 to 50 °C

Storage / transport
−40 to 70 °C

Relative humidity
Max. 95% at 25 °C

Approvals
CE, cULus, EAC, KCC, RCM

ORDERING CHECKLIST

Confirm before purchasing

Exact SINAMICS converter and Control Unit

Firmware and parameterization workflow

Direct or cabinet-door mounting

Documentation, destination and required date

FAQ

Common questions

Is this model discontinued?
No. Siemens currently lists it as PM300 Active Product.

Is there another operator-panel version?
Siemens also offers the IOP-2 family for applications needing a more advanced interface; verify compatibility with the exact drive.

Can it be door mounted?
Siemens lists door mounting kit 6SL3256-0AP00-0JA0; follow the current system documentation.

RELATED SIEMENS MODELS

Automation and drive references

6ES7512-1SM03-0AB0

6ES7954-8LL03-0AA0

6GK7243-5DX30-0XE0

6ES7522-1BL10-0AA0

6ES7288-1SR60-0AA0

6ES7512-1DM03-0AB0

6ES7155-6AA02-0BN0

6AV2181-8XP00-0AX0

6ES7136-6BA00-0CA0

6ES7288-1ST30-0AA0

6ES7216-2BD23-0XB8

6ES7953-8LP31-0AA0

6ES7155-5AA01-0AB0

6GK5005-0GA10-1AB2

6ES7288-3AT04-0AA0

6AV6671-1CB00-0AX2

6ES7315-2AG10-0AB0

6ES7521-1BL10-0AB0

6ES7512-1SK01-0AB0

6SL3210-5FE12-0UA0

6GK5774-1FX00-0AA0

6ES7214-1HG40-0XB0

6ES7214-1AG40-0XB0

6GK7243-1BX30-0XE0

Procurement support

Request availability verification, documentation matching, lifecycle review and a model check against your drive configuration.

Include: exact MLFB, quantity, Control Unit, firmware, mounting method and destination.

SEND YOUR BOM

Official technical references: Siemens Industry Mall product record, Siemens product data sheet and Siemens SINAMICS documentation.
