Name: ABB TB5600-2ETH AC500 V3 Terminal Base
Availability: InStock

ABB TB5600-2ETH AC500 V3 Terminal Base

INQUIRE NOW · ABB CONFIGURATION REVIEW

ABB TB5600-2ETH AC500 V3 Terminal Base

ABB TB5600-2ETH is the compact connection platform for an AC500 V3 CPU and its built-in communications. It organizes controller mounting, station power and field-network access in the cabinet.

ORDER CODE 1SAP110300R0278

BASE WEIGHT 0.165 kg

CONFIGURATION REVIEW Required

Order check: Confirm the intended project scope before finalizing commercial terms.

◆ Top Quality

✓ In Stock Review

✈ Fast Delivery

Request an ABB TB5600-2ETH Quote

Product information

TB5600-2ETH Connection Architecture

CPU mounting, onboard communications and expansion-bus access are shown as distinct station functions.

Controller Side

GROUP 1

CPU generationAC500 V3 only

Communication slotsNone

CPU coupler linkIntegrated

Expansion-bus roleDirect I/O connection

Expansion capacityUp to 10 modules

BASE REVIEW 0 COUPLER SLOTS

Choose this compact base only when no plug-in communication-module position is required.

Network Side

GROUP 2

Ethernet formatRJ45

Ethernet switchConfigurable

Serial portCOM1

CAN connectionDual connector

Mounting roleCabinet terminal base

MODULE ROLE

This base is designed for AC500 V3 CPUs and provides the physical connection point for the controller and its integral communication resources.

2Ethernet interfaces

1Serial interface

1CAN interface

Install TB5600-2ETH with the Correct Connectors

Power, serial, CAN and mechanical details are checked before seating the controller.

INTEGRATION & PROTECTION

01CPU seating

Inspect the base contacts and locking points before installing the controller.

02Station power

Use the designated spring connection and verify polarity before energizing.

03Cable segregation

Route communication wiring separately from disturbance-producing power conductors.

04Expansion continuity

Protect the exposed I/O-bus connector when the station is incomplete.

05Unused positions

Fit the specified protective hardware wherever an interface position is left open.

06Service safety

De-energize the station before removing the CPU or changing base wiring.

POSITIONConfirm rail space and cabinet depth.

TERMINATEPrepare each pluggable connector to the approved drawing.

INSPECTCheck bus contacts before the CPU is seated.

ABB TB5600-2ETH Buyer FAQ & Ordering Guide

Practical answers for AC500 V3 base selection, retrofit review and purchasing.

Q01

What selection condition makes ABB TB5600-2ETH the right base?

Choose ABB TB5600-2ETH when the project uses an AC500 V3 CPU and does not require a separate plug-in communication module.

Q02

How can ABB TB5600-2ETH compatibility be verified in an existing panel?

Compare the installed CPU generation, station drawing, connector layout, adjacent I/O arrangement and rail envelope before replacement.

Q03

Where is ABB TB5600-2ETH normally used?

ABB TB5600-2ETH is used as the compact cabinet base for an AC500 V3 controller station with onboard network connections.

Q04

Does the ABB page guarantee immediate stock of ABB TB5600-2ETH?

No. The product page verifies the exact identity, but current stock and lead time require a dated supplier confirmation.

Q05

Can another AC500 terminal base replace ABB TB5600-2ETH without review?

No. Bases with additional coupler positions have different width and station-planning implications, so mechanical and project checks are required.

Q06

What should be supplied when requesting ABB TB5600-2ETH manuals and pricing?

Send the CPU nameplate, full base order code, cabinet overview, connector requirement, quantity and delivery destination.
