Description: VM600 200-595-046-414: VM600 rack base plate, used for inter-module communication and power connections.
Product condition: New
Packing condition:Factory Packing
100% insured shipping: A guarantee for your purchases
PLC Autocontroller DELIVER PARTS TO WORLD.
| Manufacturer | VIBRO-METER |
| Item number | VM600 200-595-046-414 |
| Country of Origin | United States |
| Lead Time | In stock |
| After-Sales Support | 12-months |
| HS Code / Commodity code | 8537101190 |
Quotes are valid for 30 days from the day the quote is received unless stated otherwise at the time of quotation.
Yes,we offer one year warranty for all new products.
Yes. We worked with FEDEX/DHL/TNT/UPS/ allowing us to provide swift global delivery of parts to any corner of the world.
Normally 3-5 working days,some remote areas 5-7 days more.
Product Focus | Specs, Mounting & Why It Matters
What it is
The 200-595-046-414 base plate is the structural backbone of every VM600 condition-monitoring rack. Made from conductive-passivated aluminium, it provides 14 Euro-card slots, integrated power buses and rear I/O transition area — all in a 6 U × 19-inch frame only 300 mm deep.
Key parameters at a glance
|
Feature |
Value |
Note / Source |
|
Slots |
14 (4 HP pitch) |
Accepts CPU, I/O, relay, power |
|
Power buses |
+5 V, ±12 V, +24 V |
160 A aggregate, star-ground <10 mΩ |
|
Rear I/O |
96-pin Din-41612 A/B/C |
Optional transition board |
|
Material / finish |
Al alloy, conductive passivation |
0.62 kg, 96 h salt-spray |
|
Operating temp |
-20 … +70 °C |
IEC 60068-2-1/2 verified |
|
Vibration |
5 g, 10-2000 Hz |
Random, 30 min/axis |
|
Depth |
300 mm |
Needs 50 mm side clearance only |
Creative comparison---VM600 plate vs. universal 6 U sub-rack
|
Criteria |
VM600 200-595-046-414 |
Generic 6 U sub-rack |
|
Earth impedance |
<10 mΩ (star) |
>50 mΩ (daisy-chain) |
|
Max current per slot |
10 A continuous |
3 A typical |
|
Coding pins |
Yes – prevents mis-insert |
No |
|
Salt-spray rating |
1000 h (S-option) |
96 h standard |
|
Depth |
300 mm (fits 600 mm cabinet) |
350-400 mm |
Plug-in & forget
Slots are keyed and coded – CPU, I/O or power modules slide in and lock without tools. Perforated walls accept a 200 mm fan tray, guaranteeing 1 m/s airflow across card edges, essential for >100 kS/s ADCs.
Need a spare or a full rack?
One e-mail to ab@mooreplc.com covers quotation, export docs and worldwide freight – no hidden charges, no field-service fee.
