Description:SR750-P5-G5-D5-HI-A1-R：Protects and manages power feeders with overload/short-circuit protection.
Product condition: New
Packing condition:Factory Packing
100% insured shipping: A guarantee for your purchases
PLC Autocontroller DELIVER PARTS TO WORLD.
| Manufacturer | GE |
| Item number | SR750-P5-G5-D5-HI-A1-R |
| Country of Origin | United States |
| Lead Time | In stock |
| After-Sales Support | 12-months |
| HS Code / Commodity code | 8537101190 |
Quotes are valid for 30 days from the day the quote is received unless stated otherwise at the time of quotation.
Yes,we offer one year warranty for all new products.
Yes. We worked with FEDEX/DHL/TNT/UPS/ allowing us to provide swift global delivery of parts to any corner of the world.
Normally 3-5 working days,some remote areas 5-7 days more.
|
Position |
Meaning |
This Unit |
|
P |
Phase CT rated |
5 A |
|
G |
Ground CT rated |
5 A |
|
D |
Control supply |
88-300 V DC / 70-265 V AC |
|
HI |
HMI type |
Graphic LCD + 9-key keypad |
|
A1 |
I/O config |
8 DI + 4 AO |
|
R |
Comm. slot |
Redundant slot (1 extra Ethernet / fibre) |
|
Item |
Specification |
|
Phase current |
5 A (1 A optional), cont. 10 A, 1 s @ 100 A |
|
Ground current |
5 A (1 A optional) |
|
Voltage input |
100-240 V AC (LL), cont. 288 V |
|
Aux. supply |
88-300 V DC or 70-265 V AC, ≤ 15 W |
|
Output contacts |
8 (4 NO + 4 CO) 250 V AC / 8 A; 30 V DC / 8 A |
|
Digital inputs |
16, 24-250 V DC/AC auto, opto-isolated |
|
Analog outputs |
4 × 0/4-20 mA, load ≤ 1 kΩ, 0.5 % |
|
Sampling rate |
32 samples/cycle |
|
Fault recorder |
15 s max, COMTRADE export |
· 3-phase & ground OC (TOC/IOC/directional)
· Instantaneous-time, cold-load pickup
· Earth-fault, sensitive EF, harmonic EF
· OV/UV, OF/UF, voltage unbalance
· Power directional, reverse power, low power-factor
· Auto-reclose, transfer, breaker failure
· CT/VT supervision, trip-circuit monitoring
